Differential scanning calorimetry (DSC) quantifies the energy changes in reactions such as melting, transition, crystallization and glass transition temperature and is mainly used for research and development; and quality control in the fields of polymer, pharmaceutical.
Rigaku’s DSC are heat-flux types. Several models are available depending on the maximum temperature and sensitivity difference.
The high-sensitivity type DSCvesta has several available options, such as a refrigerated cooling system, an auto sample changer, sample observation, depending on the objective of the measurement.
Specifications
Product name
DSCvesta
Technique
Differential scanning calorimetry
Benefit
Characterize and quantifies the energy of a reaction associated with phase changes
Technology
DSC is a thermal analysis technique in which the difference in the amount of heat required to increase the temperature of a sample and reference is measured as a function of temperature.
Core attributes
Using this technique it is possible to observe fusion and crystallization events as well as glass transition temperatures and can be also used to study oxidation, as well as other chemical reactions.
Core options
Smart loader, sample observation unit, cooling unit
Computer
External PC
Core dimensions
380 (W) x 367 (H) x 492 (D) (mm)
Mass (core unit)
28 kg (38 kg w/ Smart loader)
Power requirements
1Ø, AC100-120V/200-240V 50/60Hz 5A
Features
High sensitivity, high performance and low noise, realized by a compact furnace
Quick gas substitution enabled by compact furnace
Remarkable heating and cooling rates that enhance the efficiency of measurement
Safety is emphasized on the entire system
Measuring temperature range: -170 to 725°C
An optional cooling unit is used for temperatures below ambient
Inert gas flow is required for temperatures above 500°C
Sample observation DSCvesta : Ambient to 350°C
(When using with cooling unit lowest temperature: -70°C)
Sample Observation Function
